250 3PH Event Distribution Board

For Data Centres that do not have the power distribution installed during commissioning or the Integrated Systems Test (IST) we can provide temporary 250A PDUs, which are compatible with all of our heat load units. We offer two variants, one being the 250 3PH Event Distribution Board.

Connection: Powerlock Drain Set – 250A 4-Pole isolator
Output: 10 x 32A 400V 5 Pin IP44 Panel Socket – 40A 3 Pole Type C MCB
Dimensions: 725mm (h) x 520mm (w) x 400mm (d)
Weight: 41kg
Maximum Load: 150kw
